| Specification (mm²) |
Overall diameter (mm) |
Approx weight (kg/m) |
Tensile Load (N) |
Current at 30℃ (A) |
Max. resistance of the Current at 30℃ (Ω/KW) |
Voltagedrop per 100m (V) |
| 3*16+1*10 | 22-27 | 1.019 | 1600 | 90 | 1.258/1.985 | 22.64 |
| 3*25+1*10 | 25-30 | 1.339 | 2300 | 120 | 0.811/1.985 | 19.46 |
| 3*35+1*16 | 30-35 | 1.826 | 3300 | 155 | 0.576/1.258 | 17.86 |
| 3*50+1*25 | 34-39 | 2.557 | 4800 | 175 | 0.401/0.811 | 14.04 |
| 3*70+1*35 | 40-45 | 3.518 | 6700 | 220 | 0.283/0.576 | 12.45 |
| 3*95+1*50 | 45-50 | 4.672 | 9200 | 260 | 0.214/0.401 | 11.13 |
| 3*120+1*70 | 51-57 | 5.943 | 11000 | 320 | 0.167/0.283 | 10.69 |
| 3*150+1*70 | 54-60 | 6.976 | 14000 | 385 | 0.134/0.283 | 10.32 |
| 3*185+1*95 | 60-66 | 8.686 | 18000 | 430 | 0.11/0.214 | 9.46 |
